Press & media kit
The machine cycle diagram that re-times itself — and your designs never leave your computer.
Everything here is free to reproduce — text, screenshots and logos — with no need to ask. Last updated 15 August 2026. Questions, review copies and interviews: [email protected].
Short description — one paragraph, ready to paste
App for calculating and communicating your machine operations and cycle times. Cyclogram is a browser-based cycle-diagram editor for machine-design engineers. It models one repeating machine cycle: every actuator is a lane, every movement a bar with optional ramp-up and ramp-down. Bindings with signed offsets chain movements, so lengthening one re-times the bound chain that follows instead of forcing a redraw. Projects stay in the user's own browser.
Long description — three paragraphs
A machine's cycle usually lives in the designer's head and gets re-explained at every hand-off — to controls, on the assembly floor, in the customer meeting. The drawing that documents it, a cyclogram, is often assembled by hand or in a spreadsheet that knows nothing about the timing, so one changed movement means re-checking every number after it. Cyclogram is a browser editor built for that drawing: one repeating cycle, one lane per actuator, one bar per movement.
Each movement is drawn as the engineer times it — an optional ramp-up, a body, an optional ramp-down. Bindings pin one of a movement's four hooks to another movement or a timeline mark with a signed offset, so "the gripper opens 0.2 s after the slide is home" survives a change to the slide. Wrap folds the timeline into its repeating loop. It is a scheduling editor, not a simulator: no physics, no collision checking, no CAD.
Cyclogram runs at cyclogram.app in a current browser and installs from Chrome or Edge as an app; after the first sign-in it works offline, needing one online start a month to refresh the session. Projects, the library and the licence live only in the browser: no project reaches the server, which keeps an account e-mail and a password hash. The free edition keeps every editing feature within two actuators and six tasks; a Full licence lifts the caps, removes the watermark and adds Excel export, free during the beta.
Boilerplate — the "About" block for the foot of a release
Cyclogram is a browser-based cycle-diagram editor for machine-design engineers, and for any process built from timed, dependent steps. It is built local-first: projects stay on the user's own computer. In free public beta until 30 September 2026; the free edition stays free afterwards. cyclogram.app · [email protected]
Screenshots — click any image to download the PNG
Taken from the running editor at 1360 × 492. The example is a rotary pick-and-place station: six actuators, twelve movements, a 6.5 s target cycle time.
Logos — SVG preferred; don't recolour or stretch
Primary, colourfor light backgroundsSVG ↓
Primary, colourfor dark backgroundsSVG ↓
Line versionfor light backgroundsSVG ↓
Line versionfor dark backgroundsSVG ↓
Monochromeone colour, light backgroundsSVG ↓
Monochromeone colour, dark backgroundsSVG ↓
Logo, PNG 512transparent backgroundPNG ↓
App icon, PNG 512the installed-app iconPNG ↓
Clear space: keep at least the height of the mark free on every side. The wordmark is set
lowercase — cyclogram. Brand colours: blue #3468e8, green
#22a476, amber #c98a1e, link blue #0b95e8.
Fact sheet
| Product | Cyclogram (the wordmark is set lowercase as "cyclogram" in the site header and logo) |
|---|---|
| Category | Browser-based cyclogram editor — also called a cycle diagram or motion diagram. A timing and scheduling editor; not a simulator, not CAD, not a Gantt or calendar tool |
| What it models | One repeating machine cycle. Each actuator is a horizontal lane; each movement is a bar with an optional ramp-up, a body and an optional ramp-down; bindings with signed offsets chain movements together |
| Core capabilities | Bindings on four hooks per movement (ramp-up start, body start, body end, ramp-down end), timeline marks and ruler, wrap view, reusable library, compare view, PDF and Excel export, 150-step undo per project |
| Who it is for | Machine-design engineers, and any process with timed, dependent steps — an embedded start-up sequence, a chemical batch procedure, a brew day |
| Website | cyclogram.app · editor at cyclogram.app/app/ · security and privacy at /security · guide for AI assistants at /ai |
| Availability | Live and in free public beta until 30 September 2026. Site and app carry © 2026 |
| Editions | Free (no licence file), Full (licence file), Enterprise (announced, in development — not shipped, and not to be described as available) |
| Free edition — caps | Every editing feature works within the caps of 2 actuators and 6 tasks. Larger projects still open, view and export, but editing them is locked until they fit the caps (or a licence is imported). Commercial use permitted, with no time limit |
| Free edition — watermark and exports | The on-screen timeline carries a tiled cyclogram.app watermark; the PDF export carries it by default and can be switched off in Preferences. Excel export is a Full-licence feature and is disabled in Free |
| Full edition | Unlimited actuators and tasks, Excel export, and watermark-free timeline and PDF. No per-feature tiering and no subscription |
| Licensing mechanism | A signed .mclic file imported once per browser, verified offline in the browser (ECDSA P-256 / SHA-256) with a local expiry check. No activation server and no phone-home. Issued to a person and tied to an account e-mail; either perpetual or valid until a date |
| Price during the beta | Every Full licence is free while the beta runs, requested through the in-app licence form or by e-mail to [email protected]. No price list is published anywhere; pricing after the beta is by e-mail |
| Account | Required to open the editor: an e-mail address and a password of at least 8 characters. Free, no card |
| Platforms | A website, nothing to install: any current Chrome, Edge, Firefox or Safari on Windows, macOS or Linux. Installs as a standalone app from Chrome or Edge, or via "Add to Home screen" on a phone |
| Offline use | Only the first sign-in needs a connection; the app then runs with no network. The cached session lasts 30 days and one online start refreshes it. Licence checks never contact a server |
| Time resolution | Snap grid of 0.1 s, 0.5 s, 1 s, 5 s, 10 s, 1 min, 10 min or 1 hour. Cycle time is derived from the last movement; the target cycle time is typed by the user |
| File formats | .mcyc project (plain indented JSON), .mclib single library entry, .mclibrary whole library with its folder tree, .mclic licence. Preferences export as plain .txt |
| Export formats | PDF: a single page rendered in the browser, page size computed from the content. Excel: an HTML table saved with an .xls extension, one cell per resolution unit. Both always print the full unwrapped cycle |
| Privacy posture | Projects, the library, preferences, the licence and the cached session live only in the user's browser (IndexedDB and localStorage) and are never uploaded. There is no server-side project storage and no cloud sync; clearing site data deletes them, so .mcyc files are the backup |
| What the server holds | An account e-mail address and a password hash (PBKDF2-SHA-256, 100,000 iterations, per-account salt), abuse counters stored as one-way hashes, and the contact details a user types into the optional in-app licence-request form. No machine designs |
| Cookies, analytics, trackers | No cookies (the session token lives in localStorage), no advertising, no tracking pixel, no third-party font, and therefore no cookie banner. Page views are counted by Cloudflare Web Analytics, which is cookie-free and stores no identifier; the single other third-party embed is Cloudflare Turnstile on the sign-up form |
| Hosting | Cloudflare: the site is deployed to Cloudflare Pages and account records live in a Cloudflare D1 database |
| Certifications | No SOC 2 report and no ISO 27001 certificate. GDPR compliance is self-assessed and the code audit is self-stated (most recently August 2026) |
| Interface languages | English, Deutsch and Slovenščina, selectable in Preferences. The ribbon, status bar and preferences translate; canvas popups and the library are English for now |
| Documentation | A 17-section manual built into the app, a 16-step interactive guided tour that runs on first launch and can be replayed, and 14 tips cards |
| Contact | [email protected] — the single address for pricing, licences, bug reports, feature suggestions, security reports and GDPR requests |
What Cyclogram is not — the errors we would most like to avoid
- Not a simulator. No physics, no collision checking. It flags two movements overlapping on the same actuator, which is a scheduling conflict, not a geometric one.
- Not CAD. No geometry, no models, no CAD import or export.
- Not a cloud tool. Projects never reach a server; there is no sync and no server-side copy of anyone's designs.
- Not a Gantt chart. One repeating cycle, times in plain seconds — not a schedule of dated tasks.
- Enterprise is announced, not shipped. Please do not describe multi-station projects, collaboration, version control or utilisation analysis as available.
Usage
The text, screenshots and logo files on this page may be used in articles, reviews, newsletters and presentations without asking. Please do not alter the logo's colours or proportions, and please do not present Cyclogram as endorsing a product or company. If you need a screenshot of something specific, a longer interview or a licence for a review, write to [email protected] and you will get a reply from the person who makes it.
